Cummins C300D5B with Engine 6LTA A9.5 -G3 240KW/220KW For Heavy Duty Equipment
Description
Technical Parameters
Cummins C300D5B Diesel Generator Set (Engine: 6LTAA9.5-G3)
Standard: 50Hz, 400/230V, cosφ=0.8, ISO 8528
1. Unit Main Parameters Table:
| Parameter Item | Specification |
|---|---|
| Genset Model | C300D5B |
| Standby Power ESP | 300kVA / 240kW |
| Prime Power PRP | 275kVA / 220kW |
| Matching Engine | 6LTAA9.5-G3 (Inline 6-cyl 9.5L Turbo & Aftercooled) |
| Alternator | Stamford S4L1D-D41 Brushless Synchronous |
| Control System | PowerCommand PC1.2 Digital Controller |
| Rated Speed | 1500rpm |
| Insulation / Protection | Class H, IP23 |
| Starting System | 24V DC Electric Start |
| 100% Prime Load Fuel Consumption | ≈58L/h |
| Standard Configuration | Base frame integrated fuel tank, industrial silencer, heavy-duty Coolpac radiator |
| Optional Accessories | Soundproof canopy, mobile trailer, ATS auto transfer switch, remote monitoring, cold start preheater, parallel module |
| Emission Standard | China Stage II / Unregulated stationary standard |
2. 6LTAA9.5-G3 Engine Technical Data:
| Parameter Item | Specification |
|---|---|
| Structure | Inline 6-cylinder, 4-stroke water-cooled, Turbocharged + Air-Air Intercooled, electronic governor |
| Displacement | 9.5L |
| Bore × Stroke | 116.5mm × 148mm |
| Compression Ratio | 16.6:1 |
| Prime Output @1500rpm | 230kW |
| Standby Output @1500rpm | 260kW |
| Lube Oil Capacity | 28.1L |
| Total Coolant Volume | 55.5L |
| Fuel Consumption Rate | ~193g/kW·h |
| Overhaul Life | ≥20,000 working hours |
| Core Advantages | Large displacement, abundant torque reserve, stable output under heavy shock loads; good low-temperature startup; global spare parts network, low maintenance cost; electronic governor ensures fast voltage recovery during load surges |
Sichuan Zhengwei Power Technology Co. Ltd., as the top Cummins dealer in the southwestern region, headquartered in Chengdu has exported 50+countries since 2009. Specializing in selling and maintenance premium diesel generator sets, Cummins engine assemblies & all range of genuine parts. Our technical expertise ensures seamless after-sales service, equipment maintenance, and global-grade support. Customer-centric, we deliver value-driven solutions to empower worldwide partnerships. Choose us and you can enjoy best one-stop procurement services with competitive.
Product Manufacturing
Engines and Generators: We specializes in the production of a wide range of engines, including diesel engines. Their diesel engine generators are highly regarded for their reliability and efficiency, suitable for various applications?
Spare Parts: We also manufactures and supplies an extensive line of spare parts for both engines and generators. This includes components like engine valves, gaskets, crankshaft front oil seals, and turbochargers. By providing high - quality spare parts, Zhengwei Power ensures the long - term performance and durability of the engines and generators it produces, as well as those of other brands in the market?
Hot Tags: Cummins C300D5B with Engine 6LTA A9.5 -G3 240KW/220KW For Heavy Duty Equipment, China Cummins C300D5B with Engine 6LTA A9.5 -G3 240KW/220KW For Heavy Duty Equipment manufacturers, factory, three phase diesel generator set, genset import agreement, prime diesel generator set, genset operation training, diesel generator, genset service contract
| Generator Sets Model | Standby Power KW |
Rated power KW | Engine No | Engine Power KW |
Cylinder diameter x Stroke MM |
compression ratio | Displacement Litre |
Generator No | Generator Excitation Method |
Standard configuration Controller | System voltage Volt |
Fuel consumption / Full load L/ hour |
lubricating oil capacity Litre |
Coolant capacity (Engine) Litre |
Coolant capacity (Water Tank) Litre |
Maximum Exhaust Back Pressure (KPa) | Minimum Cooling Ventilation Rate (m³/s) |
Combustion Air Quantity (m³/s) |
Minimum air inlet area (m³) |
Minimum Exhaust Area (m³) |
Cooling Tank Exhaust Dimensions (mm x mm) |
Fuel Tank (Liters) |
Generator Sets Model |
| C300D5B | 240 | 220 | 6LTAA9.5-G3 | 280 | 116.5×148 | 16.6:1 | 9.5 | S4L1D-D41 | Self-excited | PC1.2 | 24 | 58 | 32.4 | 11 | 44.5 | 10 | 7.9 | 0.298 | 2.34 | 1.56 | 1050×1254 | 533* | C300D5B |
